EMERSON ROC407 FLOBOSS 407 FLOW MANAGER FISHER

EMERSON ROC407 FLOBOSS 407 FLOW MANAGER FISHER (USED)

Brand: EMERSON
MPN: ROC407

EMERSON
ROC407
FLOBOSS 407
FLOW MANAGER FISHER

THE FLOBOSS 407 IS A MICROPROCESSOR-BASED FLOW COMPUTER THAT PROVIDES FUNCTIONS REQUIRED FOR GAS FLOW MEASUREMENT AND CUSTODY TRANSFER IN ACCORDANCE WITH STANDARDS, SUCH AS AGA 1985 OR 1992 ORIFICE METERING. THE FLOBOSS PROVIDES ON-SITE FUNCTIONALITY FOR APPLICATIONS WHERE THERE IS A NEED FOR REMOTE MONITORING, MEASUREMENT, DATA ARCHIVAL, COMMUNICATIONS, AND CONTROL. THE DESIGN ALLOWS YOU TO CONFIGURE THE FLOBOSS 407 FOR SPECIFIC APPLICATIONS INCLUDING THOSE REQUIRING CALCULATIONS, LOGIC, AND SEQUENCING CONTROL USING FUNCTION SEQUENCE TABLES (FST), AS WELL AS PROPORTIONAL, INTEGRAL, AND DERIVATIVE (PID) LOOP CONTROL. THE FLOBOSS 407 IS AVAILABLE IN TWO VERSIONS BASED ON THE TYPE OF APPROVAL: THE STANDARD HAZARDOUS AREA VERSION, AND THE MEASUREMENT (INDUSTRY) CANADA CUSTODY TRANSFER VERSION, WHICH INCLUDES HAZARDOUS AREA APPROVAL. THESE VERSIONS HAVE A NUMBER OF DIFFERENCES BOTH IN FIRMWARE AND HARDWARE. BOTH OF THESE VERSIONS ARE FURTHER SUBDIVIDED BY THE TYPE OF ORIFICE METERING CALCULATIONS (EITHER AGA 1992 OR AGA 1985) INCLUDED IN THE FIRMWARE ALONG WITH AGA7 TURBINE METERING CALCULATIONS.

THE FLOBOSS 407 CONSISTS OF TWO PRINTED CIRCUIT CARDS, A KEYPAD, AND A DISPLAY HOUSED IN A COMPACT WEATHER-TIGHT CASE. THE PRINTED CIRCUIT CARDS ARE THE PROCESSOR BOARD (MOUNTED ON THE DOOR) AND THE TERMINATION BOARD (MOUNTED IN THE MAIN ENCLOSURE). BUILT INTO THE TERMINATION BOARD ARE TWO ANALOG INPUT (AI) CHANNELS. MOVING JUMPER P4 ON THE TERMINATION BOARD CHANGES ONE OF THE BUILT-IN ANALOG INPUTS TO A PULSE INPUT (PI). THE PULSE INPUT CAN BE WIRED EITHER AS A FLOBOSS-POWERED OR A DEVICE-POWERED, MEDIUM-SPEED PULSE COUNTER. THE PULSE CIRCUITRY IS OPTICALLY COUPLED TO ISOLATE THE TERMINATION BOARD FROM THE INPUT SIGNAL. IN ADDITION, THE TERMINATION BOARD HAS SLOTS FOR FOUR PLUG-IN INPUT/OUTPUT (I/O) MODULES (MODULAR I/O). THE PLUG-IN I/O MODULES ALLOW ANY COMBINATION OF DISCRETE INPUTS, DISCRETE OUTPUTS, ANALOG INPUTS, ANALOG OUTPUTS, OR PULSE INPUTS THAT AN APPLICATION REQUIRES.

REF: FKM2633A11
